In modern building materials, color steel plate because of its lightweight, beautiful, convenient construction and corrosion-resistant features, become a common material in the construction of industrial plants, warehousing and logistics, temporary housing, home decoration and public facilities. With the increasingly wide application, people's attention to the service life of color steel sheet is rising. This article will systematically analyze the life cycle of color steel plate, influencing factors, prolongation methods and typical application scenarios, to help you more scientifically recognize the value of this material.
Color steel plate, also known as color coated steel, is a composite material made of organic coating after surface chemical treatment on the basis of cold rolled steel plate or galvanized steel plate. Color steel plate not only has the strength and processability of steel, but also has the corrosion resistance and decorative properties brought by the coating, so it has an irreplaceable position in the modern construction industry.
The service life of color steel plate mainly depends on its base material and surface treatment process. According to the National Standard for Cold Rolled Steel Plates and Strips (GB/T 12754-2019) and industry practice, the life expectancy of color steel sheet with different processes is as follows:
-Life expectancy: 10-15 years
-Scope of application: inland dry, less polluted environment, commonly used in ordinary factory buildings, warehousing, temporary buildings.
-Life expectancy: 20-30 years
-Features: stronger weather resistance, outstanding UV and corrosion resistance.
-Application Scenario: Coastal areas, chemical parks, areas with serious industrial pollution.
-Expected life: more than 30 years
-Cost: higher, mostly used in high-end projects or landmark buildings, such as airports, stadiums, landmark commercial buildings.
From the data, the actual life expectancy of color steel plate can be close to the theoretical value without serious mechanical damage or chemical corrosion (refer to “Metal-faced insulated sandwich panel for construction” JG/T 516-2017).
-Coastal areas: high salt content in the air, salt spray corrosion is obvious, life may be shortened by 30%-50%.
-Industrial areas: acid rain, chemical gases and dust accelerate the aging of the coating, requiring enhanced maintenance.
-Inland dry areas: low humidity in the air, less corrosive factors, life is usually closer to the theoretical value.
-If the coating is scratched or improperly cut during construction, it is easy to damage the protective layer of the substrate, thus accelerating rust and corrosion.
-Lack of regular cleaning and maintenance, dust, chemical deposits or bird droppings accumulate for a long time, will also reduce the service life.
-The thickness of common color steel plate is 0.3mm-1.0mm, the greater the thickness, the stronger the resistance to deformation and corrosion resistance.
When the thickness of substrate is lower than 0.5mm, the life and durability will be significantly reduced, and it is not suitable for long-term architectural use.
-Coating thickness, material and construction process directly affect the weather resistance of color steel plate.
-For example, Z275 galvanized layer (275g/m² zinc layer) is more resistant to long-term corrosion than Z180 galvanized layer.
- Clean the surface dust and sundries every half a year to avoid the accumulation of corrosive substances (such as bird droppings and chemical dust).
- Check whether the coating is peeling, rust spots, small area damage needs timely repair.
- For the rusted parts, first polish and remove rust, then paint special anti-corrosion primer and top coat (such as epoxy zinc yellow primer + polyurethane top coat).
- It is recommended to spray anti-corrosion coating every 3-5 years in coastal areas.
- Prohibit heavy impact or sharp objects to scratch the surface.
- Typhoon prone areas need to reinforce the fixed parts to prevent wind debris.
- Ensure that the slope of the roof is ≥5% to avoid accumulation of water leading to coating soaking and peeling off.
- Sandwich panels need to be kept ventilated to prevent condensation from rusting the inner layer.
- Reserve expansion and contraction joints (usually 0.1%-0.2% of the board length) according to the specification during installation to prevent deformation and cracking.
- Complicated problems (such as large-scale corrosion, structural deformation) should hire qualified construction unit to deal with.
(1) Preferred high zinc layer substrate: such as Z275 (zinc layer 275g/m²) is more durable than Z180.
(2) Selection of coating type:
Coating type
Applicable environment
Life expectancy
PE
Inland dry areas
10-15 years
PVDF
Coastal/industrial areas
20-25 years
(3) Brand and certification: Recognize the products in accordance with the national standard GB/T 12754 or the European standard EN 10169, and avoid the low-priced low-quality plates.
Color steel plate, with its service life and performance advantages, is widely used in.
-Industrial factory buildings and warehouses: as roof and wall panels, to meet the demand of large span and fire prevention.
-Residence and temporary construction: lightweight and easy to install, suitable for movable house and temporary shed.
-Transportation and logistics facilities: such as highway noise barriers and station buildings.
-Commercial and public buildings: used in gymnasiums, exhibition halls, shopping malls, both aesthetics and functionality.
-Agricultural buildings: such as animal husbandry plants, greenhouses, etc., strong durability.
The life of color steel plate is directly related to the whole life cycle cost of the building.
Short-life products: although the initial investment is low, the maintenance is frequent and needs to be replaced in advance, and the long-term cost is high.
-Long life product: such as PVDF color steel plate, the price is higher, but it can guarantee more than 20 years of stable use, greatly reducing the cost of maintenance and replacement.
Therefore, for long-term projects or high-end buildings, choose high life color steel plate more economic advantages.
The service life of color steel plate is closely related to the thickness of base material, coating process, environmental conditions and maintenance methods. Its service life range is generally more than 10-30 years. Through scientific selection of materials, standardized construction and regular maintenance, not only can extend the life cycle of color steel plate, but also reduce the comprehensive operating costs of the building.
With the continuous development of green building materials and new functional coatings, the future color steel plate will realize further breakthroughs in weather resistance, environmental protection and economy, and become a more reliable and long-life material choice in the field of modern construction.
